CMP/EC Single inlet medium pressure centrifugal fans, direct motor, forward curved impeller and EC Technology IE5 motor
Nominal data
Description
Medium pressure centrifugal fans and single inlet, with direct motor and forward curved impeller, with EC Technology IE5 motor with integrated electronics, specially designed for high energy efficiency.
Fan:
• Sheet steel casing.
• Forward curved impeller in extremely robust sheet steel.
• Maximum temperature of air to be carried: -25 ºC +120 ºC.
Motor:
• High efficiency EC Technology motors with integrated electronics, regulated by 0-10 V or 4-20 mA.
• IE5 efficiency motors, class F and IP55 protection.
• Single-phase 230 V 50/60 Hz.
• Working temperature: -25 ºC +60 ºC.
EC CONTROL:
Supplied as an optional accessory. Control panel for ventilation systems with EC Technology motors with the electronics integrated in the motor itself. With the following characteristics:
• CPC: Constant pressure control.
• CFC: Constant flow control.
• DAY/NIGHT: Double pressure setpoint adjustment according to time of day.
• External sensor: Compatible with temperature, humidity, air quality or CO sensor.
• Equipment preconfigured in constant pressure mode with 100 Pa set point.
Finish:
• Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment.
On request:
• Fan prepared to transport air up to +250 ºC.
• Stainless steel fan.
CMP/EC-616-2M-0.75 IE5 398x400x423
CMP/EC-620-2M-0.5 IE5 398x400x423
CMP/EC-718-2M-1 IE5 398x400x423
CMP/EC-820-2M-1.5 IE5 395x465x451
CMP/EC-820-4M-0.33 IE5 395x465x451
CMP/EC-922-4M-0.75 IE5 469x579x528
CMP/EC-1025-4M-1.5 IE5 469x579x528
